MS / HC / LC & Alloy Steel Hexazone Bars — 20mm to 60mm — High Precision Engineering
Akshat Alloys produces high-precision MS/HC/LC & Alloy Steel Hexazone (Hexagonal) Bars widely used in the fastener, nut-bolt, valve and engineering industries. Manufactured with tight across-flats (A/F) tolerances, our hexazone bars offer excellent machinability, uniform hardness and consistent surface quality for direct use in automatic screw machines and forging presses.
Available from 20mm to 60mm across flats in MS, HC45 and Alloy Steel grades. Customized lengths and special grades available on request for high-volume industrial customers.
| A/F (mm) | Area (mm²) | Wt/Metre (kg) | Std. Length |
|---|---|---|---|
| 20 mm | 346 | 2.72 | 3m / 6m |
| 22 mm | 419 | 3.29 | 3m / 6m |
| 25 mm | 541 | 4.25 | 3m / 6m |
| 27 mm | 632 | 4.96 | 3m / 6m |
| 32 mm | 886 | 6.95 | 3m / 6m |
| 36 mm | 1122 | 8.81 | 3m / 6m |
| 38 mm | 1251 | 9.82 | 3m / 6m |
| 41 mm | 1456 | 11.43 | 3m / 6m |
| 46 mm | 1832 | 14.38 | Custom |
| 50 mm | 2165 | 17.00 | Custom |
| 55 mm | 2619 | 20.56 | Custom |
| 60 mm | 3118 | 24.48 | Custom |
| Grade | Tensile (MPa) | Hardness (HB) |
|---|---|---|
| MS | 400–550 | 120–150 |
| HC45 | 700–850 | 200–240 |
| EN8 | 700–850 | 201–255 |
| EN9 | 850–1000 | 248–302 |
Across-flats dimensions held to tight tolerances ensuring accurate fit in automated screw machines and forging dies.
Uniform internal structure from Continuous Casting technology — no segregation, voids or lamination defects.
Clean surface and consistent hardness provides excellent chip formation and tool life during machining operations.
Available in grades specifically suited for nut-bolt, fastener and precision engineering industries.
High-volume stock maintained for consistent supply to fastener plants and engineering workshops across North India.
From our facility in Mandi Gobindgarh — reliable and timely delivery to your plant door anywhere in India.
Tell us your A/F size, grade and quantity — get competitive pricing directly from the manufacturer.
